| Brand Name : | UNIVO |
| Model Number : | UBPM-01 |
| Supply Ability : | 1000 Piece/Pieces per Month |
| Price : | $5.30 - $7.40/sets |
Project | Numerical value | Unit | ||
Power supply | 5±0.25 | V DC | ||
Reference temperature | 25 | °C | ||
Accuracy* | 2 | %Span | ||
Response time | 2.5ms@OSR_P=1024X | Ms | ||
SDA/SCL pull-up resistor | 4.7 | Kohm | ||
ESD HBM | 4000 | V | ||
Overload pressure | 2 | Rated | ||
Compensation temperature | 0~60 | °C | ||
Measure medium temperature | -10~85 | °C | ||
Storage temperature | -40~150 | °C | ||
Accuracy refers to the comprehensive error, which is composed of
the linearity, repeatability, hysteresis, and thermal drift errors of pressure. The pressure range and precision vary. Please consult customer service for more details. | ||||
parameter | Minimum value | Typical value | Maximum value | Unit | Remarks | ||
Power supply voltage | 2.5 | 5.5 | V | ||||
working temperature | -40 | 150 | °C | ||||
Standby current | 100 | nA | |||||
LDO output | 1.62 | 1.8 | 1.98 | V | 'regulator_sel'= 0 | ||
3.24 | 3.6 | 3.96 | V | ||||
PSRR | 60 | dB | 'regulator_sel'= 1 | ||||
resolving power | 24 | Bits | |||||
Output data resolution | 24 | Bits | LSB=(1/2^23)*VEXT ('raw_data_on'=1) | ||||
Input common mode signal suppression ratio | 80 | 110 | |||||
Built in temperature sensor accuracy | ±0.5 | °C | @25°C | ||||
±1 | °C | -40 to 85°C | |||||
Output data resolution | 16 | Bit | LSB =(1/256)°C | ||||
Clock pulse frequency | 400 | khz | I2C communication | ||||
1 | 2 | 3 | 4 | 5 | 6 | |||||
SCL | NC | GND | VDD | SDA | NC | |||||
Attention: 1. Ensure anti-static protection during the welding process 2. Overload voltage (6.5Vdc) or current (5mA) is highly likely to burn out the circuit chip. 3. Please add a 0.1uf capacitor between VDD and GND | ||||||||||
|
|
