| Model Number : | UBEL-SL01 |
| Brand Name : | UNIVO |
| Price : | $307.00/sets 1-9 sets |
Range: | 0-100mm; 200mm; 300mm; |
Power supply voltage: | 24VDC (9-30VDC) |
Comprehensive accuracy: | ± 0.1mm; |
Nonlinear: | ≤ 0.05% FS |
Repeatability: | ≤ 0.002% FS (minimum ± 1) μ M) |
Output signal: | RS485 RTU |
Environmental temperature: | -40~70℃ |
Lifetime: | ≥ 1 million times |
Update frequency: | 10Hz |
Working current: | <50mA (varies with the range) |
Insulation impedance: | ≥ 1000 M Ω/100VDC |
Humidity/Dew Point: | Humidity of 90%, no condensation allowed |
Temperature coefficient: | <30pp/C |
Electrical connection: | M12 waterproof electrical connector |
Process connection: | 10mm liquid pipe quick connector |
Protection level: | IP67 |
Connection cable: | Five core shielded cable, standard length: 1 meter |
External dimensions: | 100mm * 100 mm* 277mm |
Float specification: | 304 stainless steel material, 52 diameter large float ball |
Applicable medium: | Random liquids such as water or antifreeze (depending on the
ambient temperature of the application installation area, ensure that the liquid does not freeze) |
On demand matching: | Provide outdoor waterproof connecting pipes as needed; Antifreeze
and liquid pipes, as well as RS485 communication cables; Equipped with wireless 4G acquisition module PT500-990 and third-party monitoring platform as needed; Supporting local monitoring upper computer software as needed; |
|
|
